Technical Specifications
| Item | Unit | HPD-09GW-ACDC-TH | HPD-12GW-ACDC-TH | HPD-18GW-ACDC-TH | HPD-24GW-ACDC-TH |
| Grid Power Voltage | V/Hz | 208-240V/50Hz/60Hz, 110-120/60Hz | 208-240V/50Hz/60Hz, 110-120/60Hz | 208-240V/50Hz/60Hz | 208-240V/50Hz/60Hz |
| Solar Power Voltage | V | DC90-380V | DC90-380V | DC90-380V | DC90-380V |
| Cooling Capacity | BTU | 9000(2900-12000) | 12000(3500-15500) | 18000(6900-19000) | 24000(6900-26000) |
| Heating Capacity | BTU | 9500(800-12000) | 13000(3900-16000) | 19800(6900-19500) | 24000(6900-27000) |
| Cooling Power Input | W | 690(130-1350) | 1030(260-1700) | 1520(410-1970) | 2100(410-2600) |
| Heating Power Input | W | 670(120-1280) | 980(220-1360) | 1550(350-1670) | 2180(410-2650) |
| Max. Input Power | W | 1450 | 1870 | 2860 | 3800 |
| SEER Cooling | W/W | SEER6.6 | SEER6.6 | SEER6.6 | SEER6.6 |
| SEER Cooling | BTU/h/W | SEER22.52 | SEER22.52 | SEER22.52 | SEER22.52 |
| SCOP Heating | W/W | SCOP4.6 | SCOP4.6 | SCOP4.0 | SCOP4.0 |
| SCOP Heating | BTU/h/W | SCOP15.7 | SCOP15.7 | SCOP13.6 | SCOP13.6 |
| Air Flow Volume | m³/h | 650 | 650 | 900 | 1200 |
| Outdoor Net Dimension | mm | 795*290*555 | 795*290*555 | 795*290*555 | 860*304*733 |
| Outdoor Packing Dimension | mm | 910*400*630 | 910*400*630 | 910*400*630 | 1005*450*820 |
| Indoor Net Dimension | mm | 895*203*300 | 895*203*300 | 1000*240*310 | 1130*245*320 |
| Indoor Packing Dimension | mm | 965*275*370 | 965*275*370 | 1075*310*385 | 1195*310*390 |
| Indoor Unit Weight(Net) | Kg | 12 | 12 | 15 | 17.5 |
| Outdoor Unit Weight(Net) | Kg | 38 | 40 | 43 | 55 |
| Loading qty(20/40Q/40HQ) | 90/176/194 | 90/176/194 | 79/160/180 | 50/105/120 |
